FORTI Support & Resin Removal

The PostProcess™ FORTI™ Support & Resin Removal submersion solution delivers automated removal of PolyJet and FDM supports and excess resin for SLA, CLIP, and DLP technologies. The FORTI includes our patented Submersed Vortex Cavitation (SVC) technology – the system uses a rotating motion while the part is immersed in fluid and ensures even exposure to the induced mechanical agitation. Utilizing our proprietary software and paired with our exclusive detergents, the right amount of time, and exact temperature based on the material and geometry of the 3D printed part, the FORTI delivers precise, hands-free post-printing for additive manufacturing workflows.

Click to download the PDF Specifications or see more below.

Specifications

AUTOMAT3D® Software Features

  • Variable temperature
  • Programmable cycle time
  • Proprietary Agitation Algorithms

Hardware Features

  • Stainless steel envelope
  • Magnetically driven pump
  • Multi-configuration fixture
  • Casters for easy installation

Size and Weight

  • Envelope: 14” L x 14” W x 14” H (35.5 cm x 35.5 cm x 35.5 cm)
  • Machine Footprint: 29” L x 36” W x 43” H  (74 cm x 91 cm x 109 cm)
    • Fits through a standard door
  • Approximate Weight: 300 lbs. empty (136 kg); 470 lbs. full (213 kg)

Safety Features

  • Emergency stop
  • Auto power down

Detergent

  • Capacity: 17 Gallons (64 Liters)
  • Polyjet Materials: PLM-101-SUB
  • SLA, CLIP, and DLP Materials: PLM-403-SUB
  • FDM Materials: PLM-201-SUB

Electrical

North America

  • FORTI UHP Model (PolyJet/FDM/SLA/DLP/CLIP)
    • Power: 120V, 60Hz, Connector: NEMA 5-15P
    • Dual agitation; includes heater & ultrasonics
  • FORTI XXP Model (SLA/DLP/CLIP only)
    • Power: 120V, 60Hz, Connector: NEMA 5-15P

Europe

  • FORTI UHP Model (PolyJet/FDM/SLA/DLP/CLIP)
    • Power: 230V, 50Hz, Connector: CEE 7/3
    • Dual agitation; includes heater & ultrasonics

Consumables

All of our patent-pending engineered solutions have been developed for high-performance and optimized to use our additive formulated detergents and media. We offer our detergents in pre-mixed 5 gallon and 55 gallon containers. Concentrated versions are also available.
