CENTI Support Removal

The CENTI Support Removal Production Series solution provides all the conveniences of a compact bench-top footprint, with an envelope sized for a few large or several small geometries. Rely on the patent-pending CENTI for superior support removal for the following 3D printing technologies: FDM, SLA, PolyJet, CLIP, and more.

The CENTI includes our unique Submersed Vortex Cavitation (SVC) technology, a rotating motion while immersed in fluid for disposing support material and providing even exposure to induced mechanical agitation. Utilizing our proprietary software and paired with our exclusive detergents, the right amount of time, and exact temperature based on the material and geometry of the 3D printed part, the CENTI delivers precise, hands-free support removal from 3D printed parts.

All of our production Support Removal machines, including the CENTI, have noise reducing features for a low dBa (“library quiet” as we like to call it) and reduced heat cycle.

Click to download the PDF Specifications or see more below.

Specifications

Software Features

  • Variable temperature (70-156°F)
  • Programmable cycle times
  • Proprietary Agitation Algorithms

Hardware Features

  • Digital interface
  • Piezo-electric Ultrasonics
  • Stainless steel envelope
  • Removable envelope lid
  • Magnetically driven pump
  • Drain and hose

Size and Weight

  • Envelope: 19.5” L x 11.5” W x 6” H
  • Machine footprint: 23.5” L x 18” W x 15.5” H
  • Volume of parts should not exceed 2/3rds of envelope
  • Weight: 35 lbs. empty; 75 lbs. full

Detergent

  • Capacity: 5 Gallons
  • Polyjet Materials: PG1 Detergent
  • SLA Materials: PG1.1 Detergent
  • FDM Materials: PG2 Detergent

Electrical

  • Voltage: 110V/240V, 60/50Hz
  • Amperage: 8.5A/3.9A
  • Connector: NEMA 5-15P

Safety Features

  • Auto power down
  • Compliant with all OSHA regulations
  • Noise reducing features for a low dBa

Consumables

PostProcess Polygone Chemistry for 3D Post Printing

All of our patent-pending engineered solutions have been developed for high-performance and optimized to use our eco-friendly detergents and media. We offer our detergents in pre-mixed 5 gallon and 55 gallon containers. Concentrated versions are also available.

Learn more about Chemistry.
